Artstation 2436+Motherboard Bundle
Artstation 2436+Motherboard Bundle
Share
Couldn't load pickup availability
The UUNA TEK® ArtStation 2436 + Dedicated Motherboard Bundle combines our institutional-grade, large-format art plotter with an official backup DrawCore V1.3 motherboard to deliver ultimate reliability for continuous exhibition and studio workflows. Designed for museums, galleries, universities, and creative coding studios, the ArtStation 2436 offers an expansive 36" x 24" working area (Full ANSI / ARCH D compatible), reinforced CoreXY architecture, and high mechanical precision (0.0125 mm minimum resolution). Including a dedicated replacement motherboard ensures zero operational downtime, providing long-term maintenance security and seamless plug-and-play USB connectivity for high-capacity, unattended generative art production.
Value Propositions
-
Exhibition-Grade & Continuous Operation
Engineered for long-duration studio production, museum installations, and continuous generative art output without performance degradation.
-
Large-Format 36" x 24" CoreXY Precision
Combines a heavy-duty aluminum profile and stainless steel frame with a smooth CoreXY motion architecture, delivering 0.0125 mm minimum motion resolution across the entire ARCH D surface.
-
Multi-Media Tool Versatility
Accommodates pens, technical inks, calligraphy brushes, charcoal, and experimental tools up to 16 mm in diameter with a 45°–90° adjustable angle and dedicated servo Z-axis mechanism.
-
Plug-and-Play Drive & Seamless Connectivity
Features the upgraded DrawCore V1.3 motherboard with a CH9340 USB chip—requiring zero driver installations on modern Windows, macOS, and Linux systems.
-
Institutional Maintenance & Zero Downtime
Includes a spare, official 4-layer PCB DrawCore motherboard with built-in TVS surge protection and enhanced heat dissipation to safeguard high-stakes art production schedules.
-
Open Creative Coding Integration
Fully compatible with Inkscape, iDraw Software, and custom USB control pipelines, making it ideal for generative artists, educational research, and code-driven creative workflows.
Buy Separately vs. Buy Bundle
| Option | Included Items | Regular Price | Current Sale Price | Net Savings |
|---|---|---|---|---|
| Buy Separately |
|
$3,818.00 USD | $2,863.00 USD | — |
| Buy Bundle | ArtStation 2436 Plotter + Dedicated Motherboard Package | $3,818.00 USD | $2,290.80 USD | Save $1,527.20 USD (40% OFF Bundle Regular Price) |
- Maximum Cost Savings: Save $1,527.20 USD off the combined regular price during the promotional event.
- Institutional Protection: Having an extra mainboard on hand prevents unexpected delays during tight exhibition deadlines.
Technical Specifications
Model Name: UUNA TEK® ArtStation 2436 + Dedicated Motherboard Bundle
Working Area: 36.00" x 24.00" (915 x 610 mm) — Full ANSI / ARCH D Compatible
Motion Architecture: Reinforced CoreXY Motion System
Max XY Travel Speed: Up to 11 in/sec (280 mm/s)
Mechanical Precision (XY): 0.004" (0.1 mm)
Repeatability (XY): ±0.002" (±0.05 mm) at low speeds
Native XY Resolution: 2,032 steps/inch (80 steps/mm)
Minimum Motion Resolution: 0.0005" (0.0125 mm)
Vertical Pen Travel (Z-Axis): 0.59" (15 mm) dedicated Servo Motor system
Supported Pen Diameter: Up to 0.63" (16 mm)
Adjustable Pen Angle: 45° – 90° (supports slanted brush & calligraphy tools)
Maximum Material Thickness: 0.39" (10 mm) — Up to 0.71" (18 mm) with frame clearance adjustment
Laser Support: No (Dedicated Pen Drawing/Writing Only)
Frame & Chassis: Heavy-Duty Aluminum Profile + Stainless Steel + Magnetic Steel Plate Cover
Footprint & Dimensions: 30.43" x 41.73" x 4.53" (773 x 1060 x 115 mm)
Net Weight: 33.07 lbs (15 kg)
Included Motherboard Specifications: DrawCore V1.3 Motherboard (4-layer PCB, integrated CH9340 USB, built-in TVS surge protection, 680uF capacitor, EBB Firmware)
Connectivity & Network: Wired USB Cable (100% Offline Capable, no internet required)
Input Voltage: AC 100V – 240V (DC 12V, >=1A Output Adapter)
Compatible Software: Inkscape (iDraw ArtStation Extension), iDraw Software
Supported OS: Windows, macOS, Linux
FAQ
Q: What is the main target use for the ArtStation 2436 Bundle?
A: The ArtStation 2436 is designed for institutions, galleries, research labs, and professional generative artists requiring large-format (36" x 24"), continuous physical drawing output with zero operational downtime.
Q: Do I need to install USB drivers to use the machine?
A: No. The included DrawCore motherboard utilizes an upgraded CH9340 USB driver chip, enabling direct plug-and-play operation on Windows 10/11, macOS, and Linux without manual driver installation.
Q: Why is a dedicated spare motherboard included in this bundle?
A: For commercial studios and museum exhibition setups, machine downtime is costly. Providing a backup 4-layer PCB DrawCore mainboard ensures immediate replacement availability without waiting for maintenance shipping.
Q: Can the ArtStation 2436 use liquid ink, paintbrushes, or dry media?
A: Yes. The pen holder supports tools up to 16 mm in diameter with an adjustable angle of 45° to 90°, making it compatible with technical pens, fountain pens, paint markers, brushes, and charcoal.
Q: Does the system support wireless operation or laser engraving?
A: No. The ArtStation 2436 is a dedicated high-precision pen plotting system operating via 100% offline-capable wired USB control to ensure maximum data stability during long-duration plotting tasks.
