UUNA TEK, Co.
Artstation 1824+Motherboard Bundle
Artstation 1824+Motherboard Bundle
Share
Couldn't load pickup availability
The UUNA TEK® ArtStation 1824 + Dedicated Motherboard Bundle combines our studio-grade, medium-large format art plotter with an official backup DrawCore V1.3 motherboard to deliver continuous, zero-downtime reliability for professional artists, design agencies, and research labs. Featuring a 24" × 18" working area, reinforced CoreXY architecture, and ultra-precise motion resolution (0.0125 mm), the ArtStation 1824 transforms algorithmic and generative designs into exhibition-ready physical artwork. Including a spare 4-layer PCB DrawCore motherboard ensures long-term maintenance security and hassle-free, driverless USB plug-and-play operation for intensive studio production runs.
Value Propositions
-
Exhibition-Grade & Continuous Operation
Engineered for long-duration studio production, museum installations, and continuous generative art output without performance degradation.
-
24" × 18" CoreXY Precision Architecture
Features an aluminum profile and stainless steel structure paired with a magnetic steel working surface, delivering ultra-smooth 0.0125 mm motion resolution.
-
Multi-Media Tool Versatility
Accommodates pens, technical inks, calligraphy brushes, charcoal, and experimental tools up to 16 mm in diameter with a 45°–90° adjustable angle and dedicated servo Z-axis mechanism.
-
Plug-and-Play Drive & Seamless Connectivity
Features the upgraded DrawCore V1.3 motherboard with a CH9340 USB chip—requiring zero driver installations on modern Windows, macOS, and Linux systems.
-
Institutional Maintenance & Zero Downtime
Includes a spare, official 4-layer PCB DrawCore motherboard with built-in TVS surge protection and enhanced heat dissipation to safeguard high-stakes art production schedules.
-
Open Creative Coding Integration
Fully compatible with Inkscape, iDraw Software, and custom USB control pipelines, making it ideal for generative artists, educational research, and code-driven creative workflows.
Buy Separately vs. Buy Bundle
| Option | Included Items | Regular Price | Current Sale Price | Net Savings |
|---|---|---|---|---|
| Buy Separately |
|
$2,518.00 USD | $1,888.00 USD | — |
| Buy Bundle | ArtStation 1824 Plotter + Dedicated Motherboard Package | $2,518.00 USD | $1,510.80 USD | Save $1,007.20 USD (40% OFF Bundle Regular Price) |
- Maximum Value: Save $1,007.20 USD off the combined list price during this promotional event.
- Hardware Reliability: An extra mainboard ensures uninterrupted execution for commercial print series and gallery exhibitions.
Technical Specifications
Model Name: UUNA TEK® ArtStation 1824 + Dedicated Motherboard Bundle
Working Area: 24.00" x 18.00" (610 x 457 mm)
Motion Architecture: CoreXY Motion System
Max XY Travel Speed: 11 in/sec (280 mm/s)
Mechanical Accuracy (XY): ~0.004" (0.1 mm)
Repeatability (XY): ±0.002" (±0.05 mm) at low speeds
Minimum Motion Resolution: 0.0005" (0.0125 mm)
Vertical Pen Travel (Z-Axis): 0.39" (10 mm) dedicated Servo Motor system
Supported Pen Diameter: Up to 0.63" (16 mm)
Adjustable Pen Angle: 70° – 90° (supports slanted brush & calligraphy tools)
Maximum Material Thickness: Up to 0.71" (18 mm)
Laser Support: No (Dedicated Pen Drawing/Writing Only)
Frame & Working Surface: Aluminum Profile + Stainless Steel Structure + Magnetic Steel Working Surface
Footprint & Dimensions: 22.05" x 33.07" x 4.53" (560 x 840 x 115 mm)
Net Weight: 24.25 lbs (11 kg)
Included Motherboard Specifications: DrawCore V1.3 Motherboard (4-layer PCB, integrated CH9340 USB, built-in TVS surge protection, 680uF capacitor, EBB Firmware)
Connectivity & Network: Wired USB Cable (100% Offline Capable)
Input Voltage: AC 100V – 240V (DC 12V, >=1A Output Adapter)
Compatible Software: Inkscape (iDraw ArtStation Extension), iDraw Software
Supported OS: Windows, macOS, Linux
FAQ
Q: What is the main difference between ArtStation 1824 and ArtStation 2436?
A: The primary difference is the physical working canvas. The ArtStation 1824 features a 24" × 18" working surface (ideal for medium studio setups and standard print sizes), while the 2436 offers an expanded 36" × 24" area for ARCH D scale outputs. Both feature identical sub-millimeter precision and CoreXY motion.
Q: Why is a spare motherboard bundled with the machine?
A: Commercial creative studios and generative artists often run long, continuous plotting cycles. Having a replacement 4-layer DrawCore motherboard ready prevents project delays in case of unexpected electrical or environmental issues.
Q: Are USB drivers required for setup?
A: No. Thanks to the integrated CH9340 USB driver chip on the DrawCore V1.3 mainboard, the ArtStation 1824 connects via simple plug-and-play on modern Windows, macOS, and Linux operating systems.
Q: Can I use fountain pens, brushes, or markers with this machine?
A: Yes. The adaptive pen clamp accommodates drawing tools up to 16 mm in diameter. You can also adjust the angle between 70° and 90° for slanted brushes and fountain pen nibs.
Q: Does it require an internet connection to run?
A: No. The system operates 100% offline via a direct USB connection to ensure stable vector execution without internet interruptions.
